-The latching metal push button is a very small panel-mount latching switch. It is a SPDT with 12mm threading and 1mm pitch. This button is perfect for basic On/Off functions. Overall length (including pins) is just 22.4mm. These latched buttons are used as an Electronic Switch, and rated up to 50mA and 12VDC.
Made of aluminum and plating black surface, strong and durable. High-grade appearance and nice touch feeling. Adopt rubber ring and hexagonal nut fixed, anti dust and waterproof, which make it great for outdoors use. Metal button head durable for longstanding press.
Latching metal push button are great for electric switch, relay, power button switch, critical lights, chassis lamp, fog lamps, door switch, led switch or any circuit controls on over 500,000 cycles.
Easy to install, Screw clamp type terminals to make fiing very easy. Latching Metal Push Button provided by us is carefully manufactured with the help of utmost grade components and advanced technology as per the industry set standards. Our clients can avail this from us at the most reasonable price.
Features:
Stainless Steel Body/Nickel-plated brass Body
IP65 Weatherproof Rating
Tamper Resistant
Latching Operation Type
